Cu-OF無氧銅OF-Cu高純紅銅C103紫銅 赤銅 純凈銅 高導電導熱銅
Square Wire |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TEMPER NAME | TEMPER CODE | TENSILE STRENGTH (ksi) | MILL LIMITS | |
| TYPICAL | ||||
| Annealed | 0S050 | 35 | .0100 - .0808 inch | |
| Hard Drawn | H04 | 60 | ||
Rolled Flat
| TEMPER NAME | TEMPER CODE | TENSILE STRENGTH (ksi) | MILL LIMITS | |
| MIN | MAX | |||
| Annealed | 0S050 | 26 | 38 | Thickness: Width: |
| 1/4 Hard | H01 | 34 | 42 | |
| 1/2 Hard | H02 | 37 | 46 | |
| Hard | H04 | 43 | 52 | |
| Spring | H08 | 50 | 58 | |
Physical Properties
| (1) Expressed as a range per CDA | |
| Melting Point (Liquidis) | 1981°F |
| Melting Point (Solidus) | 1949°F |
| Density (C102 Copper Alloy) | 0.323/cu in |
| Density (C110 Copper Alloy) | (1) .321-.323 lbs/cu in |
| Electrical Resistivity (Annealed) | 10.3 ?(cir mil/ft) @ 68°F |
| Electrical Conductivity (Annealed) | 101 % IACS @ 68°F |
| Coefficient of Thermal Expansion | 0.0000098°F (68-572°F) |
| Modulus of Elasticity (Tension) | 17000 ksi |
| Modulus of Rigidity | 6400 ksi |
