C89710銅合金符合美國無鉛規范NSF372、澳洲抗脫鋅標準AS2345及歐盟RoHs認證。除水暖行業外，C89710銅合金也可應用于電氣工程，信息通信，光電等出口導向型行業。
無鉛環保易切削抗脫鋅黃銅合金的發展不僅將提升產業鏈的整體質量和價值，而且大幅度提高生產效率，降低生產成本，促進中國水暖產品在全球的高品質。
Chemical Composition
| Element |
|---|
| Cu(1) | Pb | Sn | Zn | P | Al | B | Bi | Mn | Sb |
|---|
|
| Min (%) | 61.5 |
| 0.50 |
| 0.15 | 0.15 | 0.002 | 0.15 | 0.20 | 0.25 |
|---|
| Max (%) | 62.5 | 0.10 | 0.6 | Rem | 0.20 | 0.25 | 0.005 | 0.30 | 0.40 | 0.35 |
|---|
Mechanical Properties*Form
| Temper
| Temper Code
| YS-0.2% Offset
| Elongation
(%) | Brinell Hardness, 3000 kg load
| Shear Strength
(ksi) | Compressive Yield Strength
(ksi) | Ultimate Tensile Strength in Shear
(ksi) |
|
|
|---|
| As Permanent Mold Cast | As Permanent Mold Cast | M05 | 22.5 Typ
| 39 Typ
| 73 Typ
| 35.8 Typ
| 374.5 Typ
| 52.6 Typ
|
|
|
|---|
|
Physical Properties| Melting Point - Liquidus°F | 1697 |
|---|
| Melting Point - Solidus°F | 1638 |
|---|
| Densitylb/cu in. at 68°F | 0.304 |
|---|
| Specific Gravity | 8.42 |
|---|
| Thermal ConductivityBtu/ sq ft/ ft hr/ °F at 68°F | 54.9 |
|---|
| Coefficient of Thermal Expansion 68-57210?? per °F (68 – 572°F) | 11.5 |
|---|
| Modulus of Elasticity in Tensionksi | 14240 |
|---|
| Poisson's Ratio | 0.301 |
|---|
