EN AW-AlCu6BiPb(DIN 3.1655,AA2011,FC1,A92011,AU5PbBi)德國進口易切削高強度超硬鋁合金化學成分力學性能

分享到：

微信

新浪微博

QQ空間

材質：	德國進口易切削高強度超硬鋁合金
品牌：	SCHMOLZ + BICKENBACH AG
規格：	EN AW-AlCu6BiPb(DIN 3.1655,AA2011,FC1,A92011,AU5PbBi)

產品詳情

EN AW-AlCu6BiPb(DIN 3.1655,AA2011,FC1,A92011,AU5PbBi) alloy is the most often selected for high speed automatic lathes. It offer the following advantages:
- easy machining with any equipment;
- cutting stress lower than most of other alloys;
- longer life of cutting tools;
- cutting area always clean due to very thin chip;
- high mechanical properties;
- possibility to anodize finished part in several colours.
Main applications
Screws, bolts, nuts, threaded bars.

Chemical composition

Aluminium, Al	91.4 - 95.1 %
Bismuth, Bi	0.20 - 0.60 %
Cooper, Cu	4.50 - 6.0 %
Iron, Fe	≤ 0.50 %
Lead, Pb	0.20 - 0.60 %
Magnesium, Mg	0.40 ÷ 1.80 %
Silicon, Si	≤ 0.40 %
Zink, Zn	≤ 0.30 %
Other, each	≤ 0.05 %
Other, total	≤ 0.15 %

Physical characteristics

Density	2.790 kg/dm³
Modulus of elasticity	70 000 МРа
Coefficient of thermal expansion	23.5 μm/m-°C
Thermal conductivity	T3 - 151 W/mk T8 - 171 W/mk
Electrical resistivity	T3 - 0.038 Ωmm²/m T8 - 0.043 Ωmm²/m

Mechanical properties

Temper T3 T8
Ultimate Tensile Strenght, Rm, MPa 320 370
Yield Tensile Strenght, Rp0.2, MPa 270 270
Elongiation at Break, A% 10 8
Hardness, HBW 90 105

通項公司經銷的德國鋁合金牌號：Al99.99R Al99.9H Al99.8H Al99.7H Al99.5H E-AlH Al99.98R Al99.9 Al99.8 Al99.7 Al99.5 E-Al Al99 AlRMg0.5 AlRMg1 Al99.9Mg0.5 Al99.9Mg1 Al99.85Mg0.5 Al99.85Mg1 Al99.9MgSi Al99.85MgSi Al99.8ZnMg AlFeSi AlMn0.6 AlMn1 AlMnCu AlMn0.5Mg0.5 AlMn1Mg0.5 AlMn1Mg1 AlMg1 AlMg1.5 AlMg1.8 AlMg2.5 AlMg3 AlMg4.5 AlMg5 AlMg2Mn0.3 AlMg2Mn0.8 AlMg2.7Mn AlMg4Mn AlMg4.5Mn AlMg5Mn E-AlMgSi E-AlMgSi0.5 AlMgSi0.5 AlMgSi0.7 AlMgSi1 AlMgSiPb AlMgSiCu AlCuBiPb AlCuMgPb AlCu2.5Mg0.5 AlCuMg1 AlCuMg2 AlCuSiMn AlZn1 AlZn4.5Mg1 AlZnMgCu0.5 AlZnMgCu1.5 3.3309 3.3319 3.3308 3.3318 3.3307 3.3317 3.3208 3.2307 3.4337 3.0915 3.0515 3.0517 3.0505 3.0525 3.0526 3.3315 3.3316 3.3326 3.3523 3.3535 3.3345 3.3555 3.3525 3.3527 3.3537 3.3545 3.3547 3.2305 3.3207 3.3206 3.2316 3.2315 3.0615 3.1655 3.1645 3.1305 3.1325 3.3211 3.1355 3.1255 3.4415 3.4335 3.4345 3.4365 GB-AlSi12 GB-AlSi12(Cu) GB-AlSi10Mg GB-AlSi10Mg等各種規格型號鋁板鋁棒。
